Learn How To Do Lettering

In this chapter, you will learn how to use the Text Mode to create and edit lettering, with BasePac automatically digitizing your text. After completing the videos for this chapter, you can practice with the provided exercise file and send it to us for review. By the end of this chapter, you’ll have a thorough understanding of how to create and customize your text designs in BasePac 10.

Please accept all cookies to be able to watch the video.

In this video, we will guide you through the basic functions of text mode and show you how to add and edit text effectively. Whether you’re working on simple lettering or intricate designs, this tutorial will help you navigate the key features and function available in Text Mode.

Key Points Covered:

How to activate the Text Mode
Text Input: enter text intuitively (similar to any text writing system)
Adding and Positioning Text Adjusting Text Size and Position
Needle: Select the preferred needle and change colors for individual letters.
Font Type: Choose from +120 diffrent fonts.
Alignment: Set text alignment to left, right, centered, or vertical.
Slant Angle: Create italics with slant angles from -45 to 45 degrees.
Boldness: Adjust boldness for GF fonts or change stitch length for others.
Max Text Length: Set a desired text width for consistent sizing, useful for name badges.
Text Format: Save and reuse individual sets of font types and parameters.
Envelope Function: apply specific shapes to the text
Rotation and Mirror the Text
Modifying Single Letters

By the end of this tutorial, you’ll have a thorough understanding of how to use the Basic in Text Mode to create and customize your text designs.

Please accept all cookies to be able to watch the video.

Here you will learn about the various parameters that you can set for lettering.

These parameters can be found in Text-Mode under Toolbar - parameter (gear wheel).

Key Points Covered:

Width: Adjust the width while keeping the height constant.
Character Space: Modify the gap between letters in % or mm.
Word Space: Set the word space in % or mm to alter the blank width.
Line Width: Adjust line spacing width in % or mm.
Rotation Angle: Rotate characters around their bottom left corner between -179 to 180 degrees.
Tie-off Stitches From: Define the distance between characters for inserting fixing stitches.
Type: Select the Type of fixing and lock stitches.
Trimming From: Set the trimming command between characters.
Never Cut Dots: Prevent trimming between the line and dot of characters like "j", "i", "ä", etc.
With Stitch in Connection: Insert a connection stitch between letters if there is no trim.
Connection: Define how characters connect (original, optimized, or baseline adjustments).
Fill: Set main stitch parameters like stitch distance and underlay distance.
Satin Border: Add a satin stitch around characters for special effects.
Running Border: Add a running line border around characters.
Extended Parameters: Configure additional stitch parameters found in digitizing automations.
Underlayer Options: Center Line, Contour, Zigzag
We'll also touch on Stitch Division for the letters and how you save your font style wirth the parameters under a specific name for an easy reuse.

By the end of this tutorial, you'll have a comprehensive understanding of how to adjust text parameters for optimal lettering in BasePac.

Please accept all cookies to be able to watch the video.

In this video, we'll walk you through each step to create beautifully curved text for your projects.

Key Topics Covered:

Drawing a Line or Circle
Entering Your Text on the Curve
Adjusting Text Along the Curve
Setting Vertical Position of the text
Adjust size, width, and spacing of the text
Positioning Text on a Circle
Removing Text from the Curve

By the end of this video, you'll have all the skills you need to perfectly position single-lined text along curves for any of your design projects.

Here you finde the task for the chapter lettering. After completing the videos for this chapter, you can practice with the provided exercise file.
Follow the instructions to create and customize your text designs. Once completed, send your exercise file to us for review, and we’ll provide feedback to help you improve.

Contact

You are ready with your exercise file, or you have any further questions? Contact us at software@zsk.de
Please note: Our team processes your requests from Monday to Friday, we will take care of your questions as fast as possible.
Also check our FAQ page, you might already find the answer to your question here.
