SPRINT 6XL - 12 Nadeln und 1200 mm weite!

SPRINT 6XL - 12 Needles and Extra Wide Embroidery Field

SPRINT 6XL has a long table top for the wide embroidery field of max. 1,, 200 mm.
Particularly long pieces, such as flags, bath towels or tablecloths can be embroidered perfectly.

SPRINT 6XL can also be operated in the cap and tubular modes.

SPRINT 6 - ZSK Einkopf-Stickmaschine mit 12 Nadeln

The SPRINT 6XL has a large embroidery field for wide products in the border frame with an embroidery field of 1.200 mm width and 280 mm depth.

However, the applications of the SPRINT 6XL are not limited to border embroidery; it can be quickly and easily converted to embroider caps, T-shirts and many other products in a single frame.

In tubular mode with single hoop, the SPRINT 6XL has a maximum embroidery field of 300mm x 400mm

A wide range of frames is available for the SPRINT 6 for products like shirts, jackets, shoes, socks, shirt collars, etc.



The embroidery design possibilities can be expanded with devices for sequins, beads and special threads.

SPRINT 6 Standards

SPRINT 6XL - Operation Mode Tubular

Operation Mode Tubular

SPRINT 6XL - Operation Mode Border Frame

Operation Mode Border Frame

SPRINT 6XL - Operation Mode Cap

Operation Mode Cap

ZSK STICKMASCHINEN hat den schmalsten Freiarm der Stickbranche entwickelt.

Slim tubular arm



ZSK STICKMASCHINEN has developed the slimmest tubular arm for industrial embroidery machines. Many areas and products can now be processed easily and without complications that were previously difficult or impossible to access for embroidery.

ZSK SPRINT mit 12 Nadeln

12 Needles



12 needles offer space for many different colors and different yarns for creative use. You can also improve your workflow with the placement of yarns with the highest consumption to save setup times.

Die T8 Steuereinheit für alle ZSK Stickmaschinen

T8 - Control unit



The intuitive and logical T8 control unit offers many useful functions. Use clever options such as rotating or aligning patterns on the machine, the integrated design editor or the tool for quick monograms.

ZSK Stickmaschinen der Serie SPRINT sind in allen Betriebsarten zu Hause.

Flexible for all operation modes



The SPRINT can operate in tubular, cap and flat embroidery modes. Switching between modes is quick and easy. Different equipment variants are available to meet the various operational requirements.

ZSK Stickmaschinen sind robust und langlebig.

Robust industrial machine



ZSK embroidery machines are designed for industrial use. Therefore, best quality components are of highest importance for the durable and reliable operation of ZSK embroidery machines and their outstanding embroidery qualities.

Rahmen für unzählige Anwendungen

Countless applications



For the SPRINT series there are frames for almost any application: single frames for shirts, T-shirts, jackets bags etc., cap frames, special frames for shirt collars, shoes and socks, border frames, magnetic frames etc.

Standard Features

Automatic colour change
If the embroidery design contains different colours, the machine automatically switches to the needle with the correct thread colour during embroidery.

Thread break detection
With the help of the automatic thread break detection, a ZSK embroidery machine stops automatically if the upper or lower thread breaks or the thread runs out in the bobbin.

Automatic thread tension adjustment
The automatic adjustment of the thread tension ensures a constantly optimized transport of the thread to the needle and thus enables high-quality embroideries.

Height adjustable presser foot
Adjust the presser foot to the height of the embroidery material in order to achieve better embroidery quality.

Languages
The T8 control unit can be operated in 14 different languages: English, German, Italian, French, Russian, Portuguese, Dutch, Spanish, Turkish, Polish, Hungarian, Greek, Bulgarian and Romanian.
Large integrated memory
The T8 control unit offers integrated memory for approx. 80 million stitches and thus provides space for a large number of your frequently used embroidery designs.

Barcode reader
With a barcode reader connected to the T8 via USB, barcode patterns can be loaded from a connected network and various control commands can be executed.

Connectors
A slot for the standard RJ-45 network connector and three USB ports for other devices are available for communication, memory expansion and other functionalities.

Network
The T8 works with Microsoft's network protocols and thus enables simple communication with connected company networks, digital workflow solutions or the ZSK operating data information system MY.ZSK.

MADE IN GERMANY
This machine was designed, constructed and manufactured in Germany for the high requirements of the embroidery industry.

Safety - Workplace and Workflow

Adapt your plant to operational requirements.

Our machines are already set up to meet high safety standards and comply with legal requirements. We also offer optional equipment that allows you to adapt the safety of your plant to your in-house requirements.



Safety Feature - Light Barriers
A light barrier installed in front of the working area ensures greater work safety during embroidery. As soon as the operator enters this light barrier, the embroidery process is automatically stopped.



Safety Feature - Emergency Stop Switch
The emergency stop can be used to interrupt the power supply and bring the embroidery machine to a standstill in the event of danger or to avert danger.
Safety Feature - Cover for Thread Take-Up Lever
With the thread take-up lever cover closed, 100% prevention of careless or accidental contact and injury with the levers moving rapidly up and down during operation.




Securing Workflow - Status Display
The status display provides a quick overview of the function of the embroidery machine from a distance via a multicolored light signal.

Good to know!

  • Particularly for embroidery on long pieces, such as flags, bath towels or tablecloths. Operation mode can be changed quickly for caps, hats, shoes or any kind of clothing
  • The slimmest tubular arm in the industry allows embroidery in confined spaces
  • Perfect for small and large companies
  • Robust embroidery machine for industrial 24/7 use
  • Automatic back stitch function
  • On average only 160W consumption during operation
  • Built-in universal power supply, 110 V/60 Hz and 220 V/50 Hz
  • Countless embroidery hoops and sizes for all embroidery needs
  • 360mm wide embroidery on caps
  • Optional devices for sequins, beads, cords, boring and hot air cutting
  • Coloreel suitable
  • Integrated design editor in the T8 control unit
  • Large internal memory capacity: up to 80 million stitches
  • Handles all common industry codes such as DST, DSB, KSM, DSG, EXP and more ...
  • Optional and retrofittable laser pointer
  • Loading of designs via network
  • LED illumination of embroidery area
  • Reusable environmentally friendly packaging

Applications

Bordüren Rahmen

Border frame

For applications like patches. Embroidery field max.:
1.200 mm x 280 mm

Schuhrahmen

Shoe frame

For personalization of shoes, e.g. workwear or sports

Sockenrahmen

Socks frame

For embroidery of monograms, logos or other ornaments

Kappenrahmen

Cap frame

For embroidery on caps, also 3D. Embroidrey field max.:
360 mm x 70 mm

Hemdtaschenrahmen

Shirt pocket frame

Many options to embroider shirt pockets e.g. with names or logos

Schablonenrahmen

Stencil frame

Easy embroidery of ready-made fabric labes, e.g. for name tags

Gurtbandrahmen

Belt frame

Magnetic clamping frame for belts or straps. Embroidery field: 200 mm x 90 mm

Hemdkragenrahmen

Shirt collar frame

Shirts can remain in the pak when embroidering with this frame

Mighty Hoop Magnetische Stickrahmen

Mighty Hoop

Faster embroidery  with the magnetic frames from the USA.

Klapprahmen

Foldable frames

The foldable metal frames are availaible in many variants

Smake Positionierunghilfe

Smake Jump

Accurate and reproducible design positioning

Accessories (Optional)

Optionales Zubehör ZSK SPRINT - Pailletteneinheit

Sequin Device



ZSK STICKMASCHINEN offers various extensions for embroidering sequins.



More

Optionales Zubehör ZSK SPRINT - Perlenstickeinheit

Bead Device



It is possible to process up to four different beads in one pattern.



More

Optionales Zubehör ZSK SPRINT - Kordelstickeinheit

Cording Device



A wide variety of cords and creative threads can be embroidered with the EP 1 cord embroidery unit.



More

Optionales Zubehör ZSK SPRINT - Lochbohrer

Boring Device



The device cuts a small opening into the textile, which is then automatically bordered.



More

Optionales Zubehör ZSK SPRINT - ROLL2BASKET

ROLL2BASKET



With the ROLL2BASKET textile tapes from 10 to 150mm can be embroidered from a roll.



More

Optionales Zubehör ZSK SPRINT - COLOREEL

COLOREEL



The COLOREEL unit dyes a yarn on demand, enabling new effects such as color gradients in the pattern.



More



Heads / Needles
No. Heads 1
No. Needles 12

Embroidery Field
Width 1.20 mm
Depth 280 mm
Cap 360 mm x 70 mm
Border Frame 1.200 mm x 280 mm
Tubular 460 mm x 280 mm

Embroidery Speed
Cap 1.000 rpm
Border Frame 1.200 rpm
Tubular 1.200 rpm



SPRINT 6XL - Dimensions Front View

SPRINT 6XL - Front View

Dimensions Maximum Minimum
Width 2.590 mm ( A ) 1.850 mm ( D )
Height 1.580 mm ( C ) 1.470 mm ( F )



SPRINT 6XL - Dimensons Side View

SPRINT 6XL - Side View

Dimensions Maximum Minimum
Depth 1.000 mm ( B ) 720 mm ( E )
